High Lift Pallet Truck

这里可以自定义设置

● It is a combination of a pallet truck and a lift table , suitable for internal product handling in factory workshops, operating platforms, assembly lines and the flow of semi-finished or finished products between assembly lines.

● The company's high lift trucks are equipped with double cylinders, making them smaller and more aesthetically pleasing. The user can also choose a single cylinder according to his requirements

● Fork lift up to 200 mm, with automatic fixation to ensure safety

● More scientific ergonomic design to improve operating comfort and reduce fatigue

We use nationally renowned brands of batteries as well as pumping stations to ensure working time and the power to lift.

Product parameters

high lift pallet truck

Item	Unit	Electric High lift pallet truck
Capacity	kg	1000/1500
Pump style	/	Double pump
Min fork height	mm	85
Lifting height	mm	800
Fork length	mm	1100/1200
Fork width	mm	550/685
Overall length	mm	1480
Single fork width	mm	160
Steering wheel	mm	180*50
Load wheel size	mm	70*70
Battery	V/AH	12V/65AH
Lifting motor	Kw	1.6
Wheel type	/	Nylon/PU
Feature	/	Non-movable after lifting

Product Show

high lift pallet truck

Exquisite craftsmanship

The surface of the car body are high-temperature baking paint, electrostatic spraying, smooth surface, durable, beautiful and corrosion-resistant

Ergonomic design handle

Long handle design allows the operator to maintain a safe enough distance from the vehicle, easy to lift and lower the operation

1. Emergency stop switch: When an emergency occurs, people can quickly press this button to achieve the protection measures. 2. Power display: timely replenishment of power to improve efficiency.

High quality oil cylinder

Overall sealing hydraulic cylinder, effectively avoiding oil leakage disadvantages, improve the safety performance of the whole vehicle, fast lifting, improve work efficiency.

Double-section hydraulic piston rod

Adopt thickened double-section hydraulic piston rod design, enhance the load-bearing capacity, lifting higher and faster can reduce the height of the whole vehicle retraction
